MODERN HEAVY INDUSTRIES MAIN SHOP
MDHI workshop manufactures structures for buildings, power, HRSG, and mining.
The main workshop's monthly capacity is about 4,000 to 4,500 metric tons of heavy structures or 2,500
metric tons of light-medium steel and HRSG.
Goods dispatched from the main shop are exported from
Taicang International port in Taicang City (East Suzhou), China. Taicang Port is the largest container
and bulk cargo port on the Yangtze River, aside from Shanghai Port.
Click on the image buttons below
for an interactive look inside the main shop.
- 1
BAY 1 - 4,940 ㎡
PRE-FABRICATION
+ BUILT-UP SECTIONS - 2
BAY 2 - 5,700 ㎡
HEAVY LIFT
CNC MILL, FIT & WELD - 3
BAY 3 - 4,940 ㎡
CNC BEAM LINES
BUILT-UP SECTION - 4
BAY 4 - 4,560 ㎡
ANGLE MASTER
SHOT BLASTING 1 - 5
BAY 5 - 4,560 ㎡
CLEAN & PAINT
QC HOLDING POINT - 6
BAY 6 - 6,000 ㎡
CLEAN & PAINT
QC HOLDING POINT - 7
BAY 7 - 6,000 ㎡
HEAVY FABRICATION
FIT & WELD - 8
BAY 8 - 6,000 ㎡
LARGE BLASTING
FINAL QC, PACKING - 9
BAY 9 - 2,300 ㎡
GRATING LINE
HANDRAIL, PLATFORM
BAY 3 - 4,940 ㎡ CNC BEAM LINES BUILT-UP SECTION
BAY 4 - 4,560 ㎡ ANGLE MASTER SHOT BLASTING 1
BAY 5 - 4,560 ㎡ CLEAN & PAINT QC HOLDING POINT
BAY 6 - 6,000 ㎡ CLEAN & PAINT QC HOLDING POINT
BAY 7 - 6,000 ㎡ HEAVY FABRICATION FIT & WELD
BAY 8 - 6,000 ㎡ LARGE BLASTING FINAL QC, PACKING
BAY 9 - 2,300 ㎡ GRATING LINE HANDRAIL, PLATFORM
SHOP CAFETERIA BREAK ROOMS
WELDING STORES & CONSUMABLES, 1800 ㎡
EAST YARD 6000 ㎡ FINISHED PRODUCTS PACK & LOAD
RAW MATERIAL YARD 8,000 ㎡
TRIAL ASSEMBLY AREA 4,500 ㎡
MDHI MAIN OFFICE & ADMINISTRATION
MODULAR DIVSION STAFF CAFETERIA MANAGER DORM
PAINT INSPECTION & PACKING 4,000㎡
